| SWING OVER BED | 9.05" | 229.87 mm |
| MAX CUTTING DIAMETER | 9.05" | 229.87 mm |
| MAX CUTTING LENGTH | 9.1" | 231.14 mm |
| DISTANCE BETWEEN CENTERS | 38.5" | 977.9 mm |
| X-AXIS TRAVEL | 6.5" | 165.1 mm |
| Y-AXIS | Yes | Yes |
| Y-AXIS TRAVEL | 3.93 | 3.93 |
| Z-AXIS TRAVEL | 27.5" | 698.5 mm |
| C-AXIS INDEXING | FULL CONTOURING C-AXIS | FULL CONTOURING C-AXIS |
| BAR CAPACITY | 2.62" | 66.548 mm |
| SPINDLE NOSE | A2-6 | A2-6 |
| SPINDLE MOTOR | 30 hp | 22.4 kW |
| SPINDLE SPEED | 3,500 RPM | 3,500 RPM |
| RAPID TRAVERSE RATE - X-AXIS | 1,181 in/min. | 30 m/min. |
| RAPID TRAVERSE RATE - Z-AXIS | 1,575 in/min. | 40 m/min. |
| SUB SPINDLE | Yes | Yes |
| SUB SPINDLE - BAR CAPACITY | 2.56" | 65.024 mm |
| SUB SPINDLE - SPINDLE NOSE | A2-6 | A2-6 |
| SUB SPINDLE - SPINDLE MOTOR | 25 hp | 18.6 kW |
| SUB SPINDLE - SPINDLE SPEED | 5,000 RPM | 5,000 RPM |
| SUB SPINDLE / W-AXIS TRAVEL | 28.7" | 728.98 mm |
| TURRET CAPACITY | 12 | 12 |
| TURRET TYPE | BMT55 | BMT55 |
| LIVE MILLING | Yes | Yes |
| LIVE MILLING SPEED | 5,000 RPM | 5,000 RPM |
| LIVE MILLING MOTOR | 10 hp | 7.5 kW |
| TURRET 2 CAPACITY | 12 | 12 |
| TURRET 2 TYPE | BMT55 | BMT55 |
| TURRET 2 - X-AXIS TRAVEL | 6.5" | 165.1 mm |
| TURRET 2 - Z-AXIS TRAVEL | 27.56" | 700.02 mm |
| Dimensions | 93" X 155" (W/CONVEYOR - 186") X 88.6"H | 93" X 155" (W/CONVEYOR - 186") X 88.6"H |
| Weight | 21,120 LBS | 21,120 LBS |
FANUC OiTF CNC CONTROL
TWIN 12 POSITION TURRETS UPPER AND LOWER, W/24 POSITION INDEXING ON EACH TURRET WITH BASE MOUNT TOOLING SYSTEM
Y-AXIS ON BOTH TURRETS
(2) INTEGRAL SPINDLES
FULL CONTOURING C-AXES ON BOTH SPINDLE
MILL/DRILL ON UPPER AND LOWER TURRETS
LNS SPRINT S3 BARFEED (12' BAR CAPACITY)
LNS CHIP CONVEYOR (6' DISCHARGE HEIGHT)
MISC. LIVE AND STATIC TOOLING INCLUDED IN SALE
PARTS CATCHER LEFT AND RIGHT
PROGRAMMABLE PARTS UNLOADER
PARTS CONVEYOR
BAR FEED INTERFACE
10" 3-JAW HYDRAULIC KITAGAWA CHUCK FOR LEFT SPINDLE
8" 3-JAW HYRDAULIC KITAGAWA CHUCK FOR RIGHT SPINDLE
ROYAL QG-80 COMPACT ACCU-LENGTH QUICK GRIP COLLET CHUCK W/A2-8 MOUNT - CURRENTLY INSTALLED ON BOTH SPINDLES
MACHINE WIRED FOR 220V
112 KVA STEP DOWN TRANSFORMER, 480V DELTA PRIMARY TO 208Y/120V SECONDARY (MULTI TAP)
ESTIMATED HOURS OF USE (AS SEEN IN PHOTO OF CRT):
* 11,461 HOURS OF RUN TIME
MATERIALS RUN ON THIS MACHINE: STAINLESS STEEL AND ALUMINUM
REPLACEMENT COST FOR ABOVE EQUIPPED SYSTEM IF PURCHASED NEW TODAY: $375,000 +
** AVAILABLE NOW FOR IMMEDIATE INSPECTION & PURCHASE
