| PALLET WIDTH | 19.7" | 500.38 mm |
| PALLET LENGTH | 19.7" | 500.38 mm |
| PALLET INDEXING | FULL 4TH | FULL 4TH |
| NUMBER OF PALLETS | 2 | 2 |
| MAX WORKPIECE WEIGHT | 1,540 lb | 698.5 kg |
| X-AXIS TRAVEL | 28.7" | 728.98 mm |
| Y-AXIS TRAVEL | 25.6" | 650.24 mm |
| Z-AXIS TRAVEL | 28.7" | 728.98 mm |
| SPINDLE SPEED | 12,000 RPM | 12,000 RPM |
| SPINDLE MOTOR | 25 hp | 18.6 kW |
| SPINDLE TAPER | HSK 63 | HSK 63 |
| TOOL POSITIONS (ATC) | 134 | 134 |
| RAPID TRAVERSE RATE | 1,960 in/min. | 4,978.4 cm/min. |
| CUTTING FEEDRATE | 1,960 in/min. | 4,978.4 cm/min. |
| Dimensions | 90" X 178" X 117" | 90" X 178" X 117" |
| Weight | 20,900 LBS | 20,900 LBS |
PROFESSIONAL 5 CNC CONTROL
THROUGH SPINDLE COOLANT
FULL 4TH AXIS PROGRAMMABLE PALLET
2 PALLETS
134 ATC AUTOMATION TOOL CHANGER
CHILLER
CHIP CONVEYOR
** AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
This equipment has been sold. Similar equipment available now is shown below.
