| TABLE LENGTH | 47.2" | 1,198.9 mm |
| TABLE WIDTH | 19.7" | 500.38 mm |
| TABLE CAPACITY | 1,764 lb | 800.1 kg |
| X-AXIS TRAVEL | 41.7" | 1,059.2 mm |
| Y-AXIS TRAVEL | 20.1" | 510.54 mm |
| Z-AXIS TRAVEL | 25" | 635 mm |
| SPINDLE SPEED | 10,000 RPM | 10,000 RPM |
| SPINDLE MOTOR | 20 hp | 14.9 kW |
| SPINDLE TAPER | CAT 40 | CAT 40 |
| TOOL CAPACITY (ATC) | 24 | 24 |
| RAPID TRAVERSE - X AXIS | 1,417 in/min. | 36 m/min. |
| RAPID TRAVERSE - Y AXIS | 1,417 in/min. | 36 m/min. |
| RAPID TRAVERSE - Z-AXIS | 1,181 in/min. | 30 m/min. |
| APPROX MACHINE WEIGHT | 15,500 lb | 7,030.7 kg |
| APPROX MACHINE DIMENSIONS | 120" x 83" x 111.5" | 120" x 83" x 111.5" |
FANUC 0i-MD 4-AXIS CNC CONTROL
4TH AXIS DRIVE & WIRING
24 ATC SIDEMOUNT TOOL CHANGER
OIL CHIILLER
CHIP AUGER INTO A CHIP CONVEYOR
** AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
