| Table-W | 31" | 787.4 mm |
| Table-L | 23.5" | 596.9 mm |
| Dimensions | 31" X 58" X 81" | 31" X 58" X 81" |
| Weight | 880 LBS | 880 LBS |
TABLE SIZE OVERALL WITH COOLANT TROUGH... 31" X 23.5"
TABLE SIZE WORKING SURFACE............... 26" X 18.25"
TABLE TOP HAS (4) 5/8" T-SLOTS ON 4" CENTERS
DISTANCE FROM TABLE TOP TO ELECTRODE HOLDER NOSE... 34" MAX
TRAVEL OF ELECTRODE RAM........... 9" MAX
DISTANCE LONGITUDINAL TRAVEL ADJUSTMENT OF HEAD.. 26" MAX
HEAD SWIVELS LEFT OR RIGHT 90 DEGREES
BOLT ON STYLE HEAD & ARM ASSEMBLY
ELECTRO-ARC SOLD STATE AUTO FEED
VARIABLE VOLTAGE CONTROL
VARIABLE STROKE CONTROL
WIRED SINGLE PHASE, 220 VOLTS
NO ELECTRODES OR ELECTRODE COLLETS
MAIN UNIT IS MOUNTED ON CASTERS FOR EASY PORTABILITY
NOTE: MACHINE CAME OUT OF GOVERNMENT FACILITY. LIGHTLY USED.
** AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
This equipment has been sold. Similar equipment available now is shown below.
