Used 1988 STRIPPIT SUPER 30/30 | PUNCHES, FABRICATING
ConditionUsed
1 available
1988 STRIPPIT SUPER 30/30 punch machine. 30-ton capacity, handles up to 30" material. Comes with assorted tooling, punch grinder, and accessories. Wired for 3-phase, 440V. Lightly used government surplus. Suitable for fabricating needs.
WORKING THROAT CAPACITY....... 30"
RATED TONNAGE CAPACITY........ 30 TON
CENTER LINE PUNCH TO REAR FRM. 34"
MAX HOLE DIAMETER............. 3.5" DIAM IN 12 GA
MAX MATERIAL THICKNESS........ 1" DIAM IN 1/4"
WORKING SHEET SIZE............ 30" X 30"
WORKING AREA W/ GAUGING STOPS. 30" X 30"
STROKE LENGTH................. 5/8"
HITS PER MINUT................ 165
VERTICAL TABLE ADJUSTMENT..... 2.25" MANUALLY
TRAVERSE MOVEMENT OF MATL HOLDER BAR... 27" X 29.75"
TEMPLATE WORK AREA............ 32" X 30"
LEFT SIDE OF TABLE WORK AREA.. 40" X 43.75"
DESIGNED FOR USE WITH 1.25" DIAM AND 3/5" DIAM TOOLING
(2) CABINETS FULL OF ASSORTED TOOLING
FOOT PEDAL
(2) CORNER NOTCHING ATTACHMENTS
STRIPPIT PUNCH GRINDER FOR SHARPENING TOOLING
WIRED FOR 3 PHASE, 60 CYCLE, 440 VOLTS
MACHINE CAME OUT OF GOVERNMENT FACILITY, LIGHTLY USED.
** AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
