| SWING OVER BED | 26.57" | 674.88 mm |
| MAX CUTTING DIAMETER | 14.96" | 379.98 mm |
| DISTANCE BETWEEN CENTERS | 21.2" | 538.48 mm |
| BAR CAPACITY | 3.03" | 76.962 mm |
| SPINDLE NOSE | A2-8 | A2-8 |
| SPINDLE MOTOR | 35 hp | 26.1 kW |
| SPINDLE SPEED | 4,000 RPM | 4,000 RPM |
| SUB SPINDLE | Yes | Yes |
| SUB SPINDLE - SPINDLE NOSE | A2-6 | A2-6 |
| SUB SPINDLE - SPINDLE MOTOR | 10 hp | 7.5 kW |
| SUB SPINDLE - SPINDLE SPEED | 6,000 RPM | 6,000 RPM |
| TURRET CAPACITY | 12 | 12 |
| LIVE MILLING | Yes | Yes |
| LIVE MILLING SPEED | 4,000 RPM | 4,000 RPM |
| LIVE MILLING MOTOR | 7.5 hp | 5.6 kW |
| Weight | 11,500 LBS | 11,500 LBS |
MAZATROL 640T NEXUS CONTROL
TOOLEYE
SMW AUTOBLOCK KNCS-N-225-63 3-JAW CHUCK ON MAIN SPINDLE
HAINBUCH COLLET CHUCK ON SUB SPINDLE
12 POSITION TURRET (ALL STATIONS CAN BE LIVE)
FULL C-AXIS
CHIP CONVEYOR
(3) LIVE TOOL HOLDERS
ALL AVAILABLE STATIC TOOLHOLDERS
**AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
This equipment has been sold. Similar equipment available now is shown below.
