| SWING OVER BED | 28.7" | 728.98 mm |
| SWING OVER CROSS SLIDE | 28.7" | 728.98 mm |
| SWING OVER SADDLE | 15.7" | 398.78 mm |
| MAX CUTTING DIAMETER | 25.9" | 657.86 mm |
| MAX CUTTING LENGTH | 59" | 1,498.6 mm |
| DISTANCE BETWEEN CENTERS | 73.3" | 1,861.8 mm |
| X-AXIS TRAVEL | 29.5" | 749.3 mm |
| Y-AXIS | Yes | Yes |
| Y-AXIS TRAVEL | +/-8.3" | +/-8.3" |
| Z-AXIS TRAVEL | 61" | 1,549.4 mm |
| BAR CAPACITY | 3.5" | 88.9 mm |
| SPINDLE BORE | 4.1" | 104.14 mm |
| SPINDLE NOSE | A2-8 | A2-8 |
| SPINDLE MOTOR | 30 hp | 22.4 kW |
| SPINDLE SPEED | 3,000 RPM | 3,000 RPM |
| SUB SPINDLE - SPINDLE BORE | 4.1" | 104.14 mm |
| SUB SPINDLE - SPINDLE NOSE | A2-8 | A2-8 |
| SUB SPINDLE - SPINDLE MOTOR | 30 hp | 22.4 kW |
| SUB SPINDLE - SPINDLE SPEED | 3,000 RPM | 3,000 RPM |
| B-AXIS SPINDLE MOTOR | 25 hp | 18.6 kW |
| B-AXIS MILLING SPEED | 12,000 RPM | 12,000 RPM |
| B-AXIS SPINDLE TAPER | CAPTO C6 | CAPTO C6 |
| B-AXIS TOOL POSITIONS | 100 | 100 |
| B-AXIS ROTATION | +/- 120 DEGREES | +/- 120 DEGREES |
| TURRET 2 - X-AXIS TRAVEL | 7.7" | 195.58 mm |
| TURRET 2 - Z-AXIS TRAVEL | 60" | 1,524 mm |
| Weight | 58,520 LBS | 58,520 LBS |
MSX-701III CNC CONTROL
TOOLSETTER
(2) SMX ULTIMA NCSE 315-91 3-JAW CHUCKS
LOWER TURRET (ALL POSITIONS STATIC)
CHIP CONVEYOR
LARGE ASSORTMENT OF MANUALS
REMOTE JOG HANDLE
COOLANT SYSTEM
HOURS OF USE:
- OPERATION TIME: 17,275 HOURS
- CUTTING TIME: 10,180 HOURS
** AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
This equipment has been sold. Similar equipment available now is shown below.
