| TABLE LENGTH | 64" | 1,625.6 mm |
| TABLE WIDTH | 28" | 711.2 mm |
| TABLE CAPACITY | 2,000 lb | 907.2 kg |
| X-AXIS TRAVEL | 64" | 1,625.6 mm |
| Y-AXIS TRAVEL | 32" | 812.8 mm |
| Z-AXIS TRAVEL | 30" | 762 mm |
| SPINDLE SPEED | 12,000 RPM | 12,000 RPM |
| SPINDLE MOTOR | 30 hp | 22.4 kW |
| SPINDLE TAPER | CAT 40 | CAT 40 |
| TOOL CAPACITY (ATC) | 50 | 50 |
| RAPID TRAVERSE - X AXIS | 1,200 in/min. | 30.5 m/min. |
| RAPID TRAVERSE - Y AXIS | 1,200 in/min. | 30.5 m/min. |
| RAPID TRAVERSE - Z-AXIS | 1,200 in/min. | 30.5 m/min. |
| CUTTING FEEDRATE | 833 ipm |
HAAS NEXTGEN CONTROL
RENISHAW WIRELESS INTUITIVE PROBING SYSTEM (WIPS)
PROBE RISER BLOCK
THROUGH-SPINDLE COOLANT (300 PSI)
SIDE-MOUNT TOOL CHANGER (50 ATC)
PROGRAMMABLE COOLANT NOZZLE
12,000 RPM SPINDLE
QUAD AUGER SYSTEM
CHIP CONVEYOR
CHIP STRAINER - CHIP TRAY FILTER KIT
AUXILIARY COOLANT FILTER
COOLANT TANK
COOLANT MIST CONDENSER
WINDOW BLAST
AUTOMATIC AIR GUN
XL REMOTE JOG HANDLE - TOUCHSCREEN
LOW VOLTAGE TRANSFORMER
SURGE PROTECTION
HIGH SPEED MACHINING
VISUAL PART PROGRAMMING SYSTEM
COORDINATE ROTATION & SCALING
MEDIA DISPLAY M-CODE
SPINDLE ORIENTATION
RIGID TAPPING
MACROS
HAAS CONNECT
USB PORT
ETHERNET
64GB EXPANDED MEMORY
** MACHINE CUT PRIMARILY ALUMINUM
** AS OF JUNE, 2025 - FEED CUTTING TIME HOURS: 118
** REPLACEMENT PRICE NEW AS EQUIPPED: $238,645
** UNDER POWER, AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE
This equipment has been sold. Similar equipment available now is shown below.
