| TABLE LENGTH | 59.1" | 1,501.1 mm |
| TABLE WIDTH | 26.4" | 670.56 mm |
| TABLE CAPACITY | 2,866 lb | 1,300 kg |
| X-AXIS TRAVEL | 51.2" | 1,300.5 mm |
| Y-AXIS TRAVEL | 26.4" | 670.56 mm |
| Z-AXIS TRAVEL | 24.6" | 624.84 mm |
| SPINDLE SPEED | 15,000 RPM | 15,000 RPM |
| SPINDLE MOTOR | 25 hp | 18.6 kW |
| SPINDLE TAPER | CAT 40 (BIG PLUS) | CAT 40 (BIG PLUS) |
| TOOL CAPACITY (ATC) | 40 | 40 |
| RAPID TRAVERSE - X AXIS | 1,417 in/min. | 36 m/min. |
| RAPID TRAVERSE - Z-AXIS | 1,181 in/min. | 30 m/min. |
| APPROX MACHINE WEIGHT | 20,000 lb | 9,071.9 kg |
| APPROX MACHINE DIMENSIONS | 102"L x 132"W x 122"H | 102"L x 132"W x 122"H |
| Control | CNC | CNC |
FANUC i-SERIES CNC CONTROL
THROUGH SPINDLE COOLANT
RENISHAW PROBE
BIG PLUS CAT 40 SPINDLE
40 STATION ATC (SIDE-MOUNT)
CHIP CONVEYOR
FLOOD COOLANT
REMOTE JOG
ETHERNET
** AS OF JANUARY 2026 - CUTTING TIME: 7,000 HOURS
** UNDER POWER, READY FOR IMMEDIATE INSPECTION, PURCHASE, AND REMOVAL
